TF 46
Схема розміщення ременів та ланцюгів комбайна NEW HOLLAND
Увага!!! Натисніть на посилання в колонці ОЕМ-номер для отримання більш детальної інформації
| № | ОЕМ-номер | Застосування | шт. |
| 1 | 80439496 | COOLING FAN DRIVE - INTERMEDIATE SHAFT | 1 |
| 1 | 89818570 | COOLING FAN DRIVE - INTERMEDIATE SHAFT | 1 |
| 2 | 80748003 | WATERPUMP AND ALTERNATOR DRIVE | 1 |
| 2 | 452023 | WATERPUMP AND ALTERNATOR DRIVE | 2 |
| 2 | 89832311 | WATERPUMP AND ALTERNATOR DRIVE | 2 |
| 3 | 80439495 | ROTARY DUST SCREEN DRIVE | 1 |
| 3 | 89513136 | ROTARY DUST SCREEN DRIVE | 1 |
| 5 | 381237 | COMPRESSOR DRIVE | 1 |
| 6 | 80436304 | DUST SCREEN DRIVE | 1 |
| 7 | 80186347 | BEATER DRIVE BELT | 1 |
| 8 | 9513984 | BEATER DRIVE BELT | 1 |
| 9 | 80434047 | ROTARY SEPARATOR BELT | 1 |
| 10 | 80433639 | GRAIN STORAGE DRIVE | 1 |
| 11 | 434160 | DRUM TO INTERMEDIATE SHAFT | 1 |
| 12 | 80434046 | ROTARY SEPARATOR TO ROTOR | 1 |
| 13 | 80427456 | ROTOR TO UNDERSHOT BEATER | 1 |
| 14 | 750318 | CLEANING FAN VARI - DRIVE | 1 |
| 15 | 80750166 | BEATER TO INTERMEDIATE DRIVE | 1 |
| 16 | 750290 | ENGINE TO BEATER SHAFT | 1 |
| 17 | 80445640 | UNLOADING AUGER ENGAGING | 1 |
| 17 | 9512971 | UNLOADING AUGER ENGAGING | 1 |
| 18 | 80453268 | STRAW ELEVATOR DRIVE - WITHOUT LATERAL FLOTATION | 2 |
| 18 | 9504547 | STRAW ELEVATOR DRIVE - WITH LATERAL FLOTATION | 1 |
| 18 | 9514990 | STRAW ELEVATOR DRIVE - WITH LATERAL FLOTATION | 1 |
| 19 | 350236 | BEATER TO STRAW ELEVATOR | 1 |
| 20 | 448794 | CLEANING SHOE DRIVE | 1 |
