9600 MAXIMIZER
Схема розміщення ременів та ланцюгів комбайна JOHN DEERE
Увага!!! Натисніть на посилання в колонці ОЕМ-номер для отримання більш детальної інформації
| № | ОЕМ-номер | Застосування | шт. |
| 1 | H132808 | COOLING FAN | 1 |
| 1 | H153297 | COOLING FAN | 2 |
| 2 | H143869 | ROTARY SCREEN DRIVE | 1 |
| 3 | H145158 | ROTARY SCREEN DRIVE | 1 |
| 3 | H133577 | ROTARY SCREEN DRIVE | 1 |
| 3 | H146637 | ROTARY SCREEN DRIVE | 1 |
| 3 | H146636 | ROTARY SCREEN DRIVE | 1 |
| 4 | H134437 | AIR CONDITIONING COMPRESSOR DRIVE | 1 |
| 4 | H81742 | AIR CONDITIONING COMPRESSOR DRIVE | 1 |
| 4 | H80896 | AIR CONDITIONING COMPRESSOR DRIVE | 1 |
| 5 | H135458 | CLEAN GRAIN ELEVATOR DRIVE | 1 |
| 5 | H141166 | CLEAN GRAIN ELEVATOR DRIVE | 1 |
| 6 | H162629 | CYLINDER DRIVE INTERMEDIATE | 1 |
| 6 | H210476 | CYLINDER DRIVE INTERMEDIATE | 1 |
| 7 | H115881 | CYLINDER DRIVE REGULAR DUAL-RANGE AND SINGLE RANGE | 1 |
| 7 | H118618 | CYLINDER DRIVE, SLOW SPEED | 1 |
| 8 | N110085 | TAILINGS AUGER AND ELEVATOR (LOWER) | 1 |
| 9 | H125565 | HEADER AND REEL PUMP | 1 |
| 9 | H140160 | HEADER AND REEL PUMP | 1 |
| 10 | H125380 | STRAW CHOPPER DRIVE, FRONT | 1 |
| 10 | H157726 | STRAW CHOPPER DRIVE, FRONT - FINE CHOPPER | 1 |
| 10 | P47885 | CHOPPER IN WINDROW OR FORWARD POSITION | 1 |
| 10 | H23950 | CHOPPER IN WINDROW OR FORWARD POSITION | 1 |
| 10 | H125381 | CHOPPER IN REAR (OPERATING) POSITION | 1 |
| 11 | H137264 | (490-980 RPM) OPT. SPEED | 1 |
| 11 | H140404 | (750-1350 RPM) STANDARD SPEED | 1 |
| 11 | H152146 | (750-1600 RPM) STANDARD SPEED | 1 |
| 11 | H152180 | (490-980 RPM) OPT. SPEED | 1 |
| 12 | H126345 | FEEDER HOUSE FIXED SPEED WITH REVERSER | 1 |
| 13 | H125711 | FEEDER DRIVE VARIABLE SPEED | 1 |
| 14 | H128234 | STRAW SPREADER DRIVE | 1 |
| 15 | RE44538 | FOR ALTERNATOR | 2 |
